GLEB22-1/C-RD - Rotary Switch - 1 Contact (1/C) - 22mm - Red
Precio original
$5.96
-
Precio original
$5.96
Precio original
$5.96
$5.96
-
$5.96
Precio actual
$5.96
SKU GLEB22-1C-RD
Disponibilidad:
en stock, listo para ser enviado
Rotary head switches resemble mushroom head buttons but are turned rather than pushed. To operate, you must rotate it in the direction displayed on top. Rotating it will open/close your electrica circuit connection. Then release it back to its default position in order to close/open it.
Dimensions & Features:
None
Dimensions & Features:
Type: | Rotary Switch |
Mounting Hole Size: | 22mm |
Color: | Red |
Type of Contact: | 1/C |
Number of Contacts: | 1 |
Voltage Rating: | 240V |
Enclosure Material: | Reinforced Thermoplastic |
Contact Material: | Silver |
Protection Degree: | IP 65 |
Storage Temperature: | -40oC to 80oC |
Operating Temperature: | -25oC to 70oC |
UL Approved: | Yes |
CE Certified: | Yes |
RoHS Compliant: | Yes |
Cross References
Cross Reference Parts:None
