CEF2214 - Steel Closed End Connector - 22 AWG to 14 AWG
Original price
$4.74
-
Original price
$4.74
Original price
$4.74
$4.74
-
$4.74
Current price
$4.74
SKU CEF2214
Availability:
in stock, ready to be shipped
Series CE closed end crimpable connectors are designed for use with both stranded and solid wires. They are vibration, chemical and corrosion resistant
Product Drawing:
None:
Wire Range: | 22-14 AWG |
L: | 0.598" (15.2mm) |
F: | 0.362" (9.2mm) |
D: | 0.287" (7.3mm) |
W: | 0.196" (5.0mm) |
T: | 0.01" (0.25mm) |
E: | 0.28" (7.0mm) |
C: | 0.102" (2.6mm) |
Terminal Material: | Steel |
Insulation Material: | UL Approved 94U-V Nylon 6/6 |
Color: | Natural |
Temperature Rating: | 105oC - 600 Volts |
UL Recognized: | Yes |
CE Certified: | Yes |
RoHS Compliant: | Yes |
Product Drawing:
Cross References
Cross Reference Parts:None:
