DRVBL10-1 - DIN46237 Vinyl Ring Terminal Brazed 22-16 AWG - 3/8" Stud
Original price
$15.94
-
Original price
$15.94
Original price
$15.94
$15.94
-
$15.94
Current price
$15.94
SKU DRVBL10-1
Availability:
in stock, ready to be shipped
| PRODUCT DESCRIPTION | |||
|
Ring tongue design offers a tight and secure connection in high vibration areas, Vinyl insulation sleeve is securely fastened to metal insulation grip sleeve, providing protection to crimp joint. Color coded according to industry standards Internal barrel serrations offer good wire contact and maximum tensile strength. |
|||
| DIMENSIONS AND FEATURES | |||
| T: | 0.8mm (.03") | Wire Range: | 22-16 AWG |
| L: | 24mm (0.94") | Color: | Red |
| E: | 10mm (0.39") | Terminal Material: | Tin-Plated Copper |
| W: | 18mm (0.71") | Terminal Insulation: | Vinyl |
| D: | 4mm (0.16") | Max Electrical Rating: | 600 Volts 105oC |
| D1: | 1.6mm (.06") | Max Electrical AMP: | 18AMP |
| D2: | 10.5mm (0.41") | Stud Size: | 3/8 |
| UL Recognized: | Yes | ||
| CE Certified: | Yes | ||
| RoHS Compliant: | Yes | ||
|
