2/0 AWG Non Insulated Flag Style Ring Terminals, 5/16" Stud, 25 Pieces - FGNB70-8

Sold out
Original price $109.44 - Original price $109.44
Original price
$109.44
$109.44 - $109.44
Current price $109.44
SKU FGNB70-8
Availability:
Out of stock
Piece Quantity: 25 Pieces

NON INSULATED FLAG STYLE RING TERMINALS

Our Flag Style Ring Terminals, also known as "Ring Tongue Terminals" feature a 90 degree orientation which makes the crimp more convenient and allows the ring terminal to be used in confined spaces. In some applications, this terminal can also be used to avoid bending your wire to orient it with a traditional ring terminal.

DIMENSIONS & FEATURES:

Wire Size: 2/0 AWG
Stud Size: 5/16"
D: 17.5mm (0.689")
D1: 13.1mm (0.516")
T: 2.0mm (0.079")
L: 46.7mm (1.839")
F: 17.3mm (0.681")
W: 23.9mm (0.941")
D2: 8.4mm (0.331")
Material: Tin-Plated Copper
Seam Type: Brazed
Temperature Rating: 105oC
Max Electrical Current: 265A
CE Certified: Yes
RoHS Compliant: Yes

PRODUCT DRAWING:
DOWNLOAD THE SPEC SHEET HERE:
