HC1021N - Self-adhesive Tie Mounts - 30 x 30 x 7mm - With Mounting Holes - Natural
Original price
$0.00
-
Original price
$13.50
Original price
$13.50
$0.00
-
$13.50
Current price
$13.50
SKU HC1021N
Availability:
in stock, ready to be shipped
Availability:
Out of stock
Self-adhesive tie mounts offer lightweight support to wire bundles. For added support of heavy wire bundles, tie mounts are also available with a screw mounting hole. Always apply on a clean, smooth, grease-free surface.
Dimensions & Features:
Technical Drawing:
None
Dimensions & Features:
| Size: | 30x30x7mm |
| Color: | Natural |
| L: | 30mm (1.18") |
| W: | 30mm (1.18") |
| H: | 7mm (0.28") |
| T: | 9mm (0.35") |
| Mounting Holes: | 3.8mm (0.15") |
| Service Temperature: | -40°F to 185°F (-40°C to 85°C) |
| Material: | UL Approved 94UV-2 Nylon 6/6 |
| UL Approved: | No |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Technical Drawing:
Cross References
Cross Reference Parts:None
