HC103N - Self-Adhesive Tie Mount - 40 x 40 x 12.5mm - Natural - With Mounting Holes
Original price
$17.80
-
Original price
$17.80
Original price
$17.80
$17.80
-
$17.80
Current price
$17.80
SKU HC103N
Availability:
in stock, ready to be shipped
Self-adhesive tie mounts offer lightweight support to wire bundles. For added support of heavy wire bundles, tie mounts are also available with a screw mounting hole. Always apply on a clean, smooth, grease-free surface.
Dimensions & Features:
Technical Drawing:
None
Dimensions & Features:
| Size: | 40 x 40 x 12.5mm |
| Color: | Natural |
| L: | 40mm (1.57") |
| W: | 40mm (1.57") |
| H: | 8mm (0.31") |
| T: | 12.5mm (0.49") |
| Mounting Holes: |
4.2mm (0.16") |
| Material: | UL Approved 94UV-2 Nylon 6/6 |
| Service Temperature: | -40°F to 185°F (-40°C to 85°C) |
| UL Approved: | No |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Technical Drawing:
Cross References
Cross Reference Parts:None
Documents
Click to view product spec sheet:Videos
