MDFN5-250 - MALE 12-10AWG Fully Insulated Quick Disconnects - Nylon
Original price
$5.42
-
Original price
$5.42
Original price
$5.42
$5.42
-
$5.42
Current price
$5.42
SKU MDFN5-250
Availability:
in stock, ready to be shipped
Quick disconnects create a splice when fitted together to easily connect or disconnect without causing damage to the terminal or insulation.
Dimensions & Features:
Product Drawing:
None
Dimensions & Features:
| Wire Size: | 12-10 AWG |
| Terminal Material: | Tin-Plated Copper |
| Insulation Material: | Nylon |
| Insulation Profile: | Oval |
| Color: | Yellow |
| Nema Tab: | 0.8 x 6.35mm (0.03 x 0.25") |
| Temperature Rating: | 75oC |
| Voltage Rating: | 300 Volts |
| Max Electrical Current: | 24 AMP |
| T: | 0.40mm (0.02") |
| L: | 25.0mm (0.96") |
| F: | 7.7mm (0.30") |
| B: | 13.0mm (0.51") |
| W: | 6.4mm (0.25") |
| D: | 6.4mm (0.25") |
| C: | 2.3mm (0.09") |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Product Drawing:
Cross References
Cross Reference Parts:None
