16 to 14 AWG PVC Vinyl Insulated Ring Terminals, 5/16" Stud, Butted Seam, 100 Pieces - RV2-8
Original price
$12.13
-
Original price
$12.13
Original price
$12.13
$12.13
-
$12.13
Current price
$12.13
SKU RV2-8
Availability:
in stock, ready to be shipped
VINYL (PVC) INSULATED RING TERMINALS
Ring terminals offer a tight and secure connection in high vibration areas. Simply crimp the ring terminals to your stranded wires to be attached to studs or posts. Vinyl Insulated ring terminals come in a variety of sizes and styles in a brazed or butted format.
Application Info:
Ring terminals (sometimes called split ring terminals): electrical contact is made by the flat surface of the ring, while mechanically they are attached by passing a screw or bolt through them. Their sizes can be determined by the gauge (AWG) of the conducting wire, and the interior and exterior diameters.
Dimensions & Features:
| Wire Size: | 16-14 AWG |
| T: | 0.8mm (0.03") |
| L: | 26.8mm (1.10") |
| F: | 11mm (0.43") |
| E: | 10mm (0.39") |
| W: | 12mm (0.47") |
| D | 4.5mm (0.16") |
| D1: | 2.3mm (0.09") |
| D2: | 8.4mm (0.33") |
| Stud Size: | 5/16" |
| Color: | Blue |
| Terminal Material: | Tin-Plated Copper |
| Insulation Material: | Vinyl |
| Max Electrical Rating: | 600 Volts (105oC) |
| Seam: | Butted |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Technical Drawing:
Cross References
Cross References:3M: MVU14-14R/SK
Burndy: TP14-14
Cembre: BVF-R 14
Eclipse: 902-444-10
Elecdirect: R4B14BS
McMaster-Carr: 7113K25
Panduit: PV14-14R-C
Weidmuller: 1492440000
