22 to 16 AWG 3-Way Splice Connectors, #8 Stud, Vinyl PVC Insulated, 10 Pieces - 3WCV1
Precio original
$4.35
-
Precio original
$4.35
Precio original
$4.35
$4.35
-
$4.35
Precio actual
$4.35
SKU 3WCV1
Disponibilidad:
en stock, listo para ser enviado
3-WAY CONNECTOR TERMINAL SPLICES
Vinyl PVC 3-Way Connectors (also known as Terminal Splices) securely connect three wires with one terminal. Constructed of three ring terminals riveted together through the stud holes. The vinyl insulation prevents incidental metal to metal contact that can cause shorts. Requires one crimp per wire.
DIMENSIONS & FEATURES:
| Wire Range: | 22 to 16 AWG |
| Color: | Red |
| L: | 0.67" (17.0mm) |
| D: | 0.16" (4.0mm) |
| E: | 0.39" (10.0mm) |
| D1: | 0.07" (1.7mm) |
| D2: | 0.16" (4.0mm) |
| Terminal Material: | Tin-Plated Copper |
| Insulation Material: | Vinyl (PVC) |
| Stud Size: | #8 Stud |
| Temperature Rating: | 75oC |
| Voltage Rating: | 600 Volts |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
DRAWING:
Cross References
Cross Reference Parts:
None
Documents
Click to view product spec sheet:
