1" NPT Thread Nylon Cable Gland, Black, with 2x12mm Two-Hole Seal - NPT1-BK-212S
NYLON CABLE GLANDS: NPT THREAD
The MiroSeal brand of cable glands is our new house offering at a more affordable price for those that do not need to meet the UL approval standards. Please be sure to visit our product page for the complete line of MiroSeal products. Also, please note: MiroSeal glands and accessories are not cross compatible with other glands available on the site.
NPT (National Pipe Thread) cable glands are useful when creating water-tight pass-throughs for cables. They protect and secure cables through their internal seals. Ferrules Direct offers a wide range of NPT sizes in a variety of materials and colors. These glands are easy to use and built to handle tough conditions.
1" NPT Nylon Cable Gland with 12mm 2-Hole Seal
- Lock-nut Included ✓
- 12mm 2-Hole Inner Gland Seal Included ✓
- O-Ring Included ✓
- NPT-1 (1-inch)
- IP68 Rating ✓
| Thread Size: | NPT 1" |
| Seal: | 2x12mm 2-Hole Seal |
| Color: | Black |
| C1: | 33.3mm (1.31") |
| C2: | 26.7mm (1.05") |
| D2: | 32.0mm (1.25") |
| B1: | N/A |
| L1: | 16.0mm (0.63") |
| L2: | 32.0mm (1.25") |
| L3: | 25.1mm (0.98") |
| Material: | UL Approved 94UV-2 |
| Ingress Protection: | IP68 |
| Flammability: | PA (Nylon), UL 94 |
| Hermetic Seal: | NBR (Nitrile Rubber) |
| O-Ring: | EPDM |
| Working Temperature: | -40°C to 105°C |
| UL Recognized: | No |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Product Drawing:
Additional Information:
A cable gland (more often known in the U.S. as a cord grip, cable strain relief, cable connector or cable fitting) is a device designed to attach and secure the end of an electrical cable to the equipment. A cable gland provides strain-relief and connects by a means suitable for the type and description of cable for which it is designed—including provision for making electrical connection to the armor or braid and lead or aluminum sheath of the cable, if any. Cable glands may also be used for sealing cables passing through bulkheads or gland plates. Cable glands are mostly used for cables with diameters between 1 mm and 75 mm.
