FSNYDM2-4 - Nylon Flange Spade Terminal Double Crimp - 16-14 AWG - Blue
Precio original
$25.58
-
Precio original
$25.58
Precio original
$25.58
$25.58
-
$25.58
Precio actual
$25.58
SKU FSNYDM2-4
Disponibilidad:
en stock, listo para ser enviado
Nylon insulated spade terminals lock in place for tight and secure connection in cramped spaces. They allow the end user to quickly and easily terminate a connection without the need to remove the fastener. Internal barrel serrations ensure good wire contact and maximum tensile strength. UL Flammability UL94V-2
Dimensions & Features:
Technical Drawing:
None
Dimensions & Features:
Wire Size: | 16-14 AWG |
Stud Size: | #8 Stud |
Color: | Blue |
T: | 0.8mm (0.03") |
L: | 24mm (0.95") |
F: | 6.8mm (0.27") |
E: | 11mm (0.43") |
W: | 8mm (0.32") |
A: | 1.5mm (0.06") |
D: | 4.5mm (0.18") |
D1: | 2.3mm (0.09") |
D2: | 4.3mm (0.17") |
Seam: | Brazed |
Terminal Material: | Tin-Plated Copper |
Max Electrical Rating: | 105°C - 600 Volts |
Max Amp Rating: | 30A |
UL Recognized: | Yes |
CE Certified: | Yes |
RoHS Compliant: | Yes |
Technical Drawing:
Cross References
Cross Reference Parts:None
