22mm Rotary Switch Push Button, NO & NC Contacts, 110-240v, 1 Piece - LMB22-NOC-RD
Agotado
Precio original
$8.40
-
Precio original
$8.40
Precio original
$8.40
$8.40
-
$8.40
Precio actual
$8.40
SKU LMB22-NOC-RD
Disponibilidad:
Agotado
Rotary head switches resemble mushroom head buttons but are turned rather than pushed. To operate, you must rotate it in the direction displayed on top. Rotating it will open/close your electrica circuit connection. Then release it back to its default position in order to close/open it.
Dimensions & Features:
None
Dimensions & Features:
| Type: | Rotary Push Button Switch |
| Mounting Hole Size: | 22mm |
| Color: | Red |
| Type of Contact: | Normally Open (NO) + Normally Closed (NC) |
| Number of Contacts: | 1 |
| Voltage Rating: | 110v-240v |
| Enclosure Material: | Reinforced Thermoplastic |
| Contact Material: | Silver |
| Protection Degree: | IP 65 |
| Storage Temperature: | -40oC to 80oC |
| Operating Temperature: | -25oC to 70oC |
| UL Approved: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
| Manufacturer: | Auspicious (LMB22-10C R) |
Cross References
Cross Reference Parts:None
