PG21 Right Angle Cable Gland - 9-16mm - Gray - PG2116RA-GY
Precio original
$3.42
-
Precio original
$3.42
Precio original
$3.42
$3.42
-
$3.42
Precio actual
$3.42
SKU PG2116RA-GY
Disponibilidad:
en stock, listo para ser enviado
Right Angle PG Thread Gray Cable Gland (Includes both locknut and washer)
Dimensions & Features:
Product Drawing:
None
Dimensions & Features:
Thread Size: | PG21 |
Cable Range: | 9-16mm |
Color: | Gray |
C1: | 28.3mm (1.11") |
C2: | 26.9mm (1.06") |
D2: | 23.1mm (0.91") |
B1: | 16.1mm (0.63") |
H: | 41.2mm (1.62") |
L: | 66.4mm (2.61") |
L1: | 10.1mm (0.40") |
L2: | 14.2mm (0.56") |
L3: | 22.8mm (0.90") |
Material: | UL Approved 94UV-2 |
Flammability: | PA (Nylon), UL 94 |
Hermetic Seal: | NBR (Nitrile Rubber) |
O-Ring: | EPDM |
Working Temperature: | -40°C to 105°C |
UL Recognized: | Yes |
CE Certified: | Yes |
RoHS Compliant: | Yes |
Product Drawing:
Cross References
Cross Reference Parts:None
