RNI1-32 - 22 to 16 AWG Polycarbonate Ring Terminals, #4 Stud, 100 Pieces
Precio original
$8.82
-
Precio original
$8.82
Precio original
$8.82
$8.82
-
$8.82
Precio actual
$8.82
SKU RNI1-32
Quantity: 100 Pieces
Disponibilidad:
en stock, listo para ser enviado
Ring terminals offer a tight and secure connection in high vibration areas. The insulated sleeve is securely fastened to metal grip sleeve providing protection to the crimp joint. Color coded according to industry standards.
Dimensions & Features:
| Wire Size: | 22-16 AWG |
| Stud Size: | #4 Stud |
| Color: | Red |
| T: | 0.75mm (0.03") |
| L: | 18.5mm (0.728") |
| F: | 5.0mm (0.197") |
| E: | 11mm (0.433") |
| W: | 5.5mm (0.217") |
| D | 4.0mm (0.157") |
| D1: | 1.7mm (0.067") |
| D2: | 3.2mm (0.126") |
| Terminal Material: | Tin-Plated Copper |
| Insulation Material: | Polycarbonate |
| Max Electrical Rating: | 600 Volts (105oC) |
| Seam: | Butted |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Technical Drawing:
