20" Light Heavy Duty Cable Ties, 120-lb Tensile Strength, Black, UV Resistant, UL Approved, 100-Pack - CTHD500N
Original price
$11.08
-
Original price
$11.08
Original price
$11.08
$11.08
-
$11.08
Current price
$11.08
SKU CTHD500N
Availability:
in stock, ready to be shipped
NYLON CABLE TIES - LIGHT HEAVY DUTY SERIES
A cable tie is a band or length of strap, manufactured from materials known as polyamides (Nylon 6/6). The width, length, and head of the cable tie has a ratcheting mechanism, that allows for locking or bundling items together.
These cable ties have an excellent resistance to oils, oil derivatives, and chloride solvents. Limited resistance to acids. No resistance to phenols.
Formerly sold under stock #: CT500N
DIMENSIONS & FEATURES:
Length: | 19.7" (500mm) |
Width: | 0.30" (7.6mm) |
Color: | Natural |
Maximum Bundle Diameter: | 150mm (5.9") |
Minimum Bundle Diameter: | 0.33" (8.50mm) |
Tensile Strength: | 120lbs (54.43kg) |
Material Brand: | Dupont, Ascend |
Flammability Rating: | UL 94 V-2 |
Material: | UL Approved 94 V-2 Nylon 6/6 |
Operating Temperature: | -40oC to 85oC (-40oF to 185oF) |
Gamma Resistance: | 1x10 Rads |
UL Approved: | Yes |
RoHS Compliant: | Yes |
CE Certified: | Yes |
TUV Approved: | Yes |
DRAWING:
Cross References
Cross Reference Parts:
None
Documents
Click to view product spec sheet:
