AD05008 - 22 & 20 AWG (8mm Pin) Insulated Ferrules - White
Original price
$0.00
-
Original price
$6.99
Original price
$6.99
$0.00
-
$6.99
Current price
$6.99
SKU AD05008
Availability:
in stock, ready to be shipped
Availability:
Out of stock
A Wire Ferrule is a connector used to terminate stranded wires (sometimes referred to as a cord end terminal or bootlace ferrule). Traditionally a wire ferrule is crimped to a stranded wire using a crimping tool (compression, ratchet, or pneumatic mechanism), thus turning the stranded wire into a solid one. Wire Ferrules are offered without insulation (Non-Insulated Wire Ferrules), with plastic insulation for single wires (Single Insulated Wire Ferrules) and with a plastic insulation to accommodate two wires (Twin Wire Ferrules). Wire Ferrules are offered in Strips or Spools to be used with automatic crimping machines or multi-function crimping tools.
Dimensions & Features:
Dimensions & Features:
| Wire Size: | 22 & 20 AWG |
| Color: | White |
| L1: | 14.0mm (0.551") |
| L2: | 8.0mm (0.315") |
| D: | 1.3mm (0.051") |
| D1: | 1.0mm (0.039") |
| D2: | 2.6mm (0.102") |
| UL Approved: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
| Max Electrical Rating: | 105°C (221°F) - 600 Volts |
| Max Electrical Current: | 12A |
Technical Drawing:
Cross References
Cross Reference Parts:ABB: XUSD01830 & 30445400
Altech Corp: 2864.0 FID2006
AutomationDirect: V30AE000038
Crimp Supply: 13A11004
Elecdirect: FER-22-6D
Greenlee: 469/6
McMaster-Carr: 7950K81 & 7950K11 & 7950K12
Panduit: FSD75-8-D FSF75-8-D
Phoenix Contact: 3200687
Power Phase - Fastenal: 0749601
RS PRO: 458-689
SPC Technology: SPC4504 84N2038
Thomas Betts: F2020
Tyco AMP: 966 067-1
WAGO: 216-221
Miromar: 120050/8
American Electrical: 1181050
Weidmuller: 9019000000
Z+F: V30AE000038
