22 AWG (6mm Pin) Insulated Ferrules - Pink

$8.69
SKU AT03406
Quantity Options
A Wire Ferrule is a connector used to terminate stranded wires (sometimes referred to as a cord end terminal or bootlace ferrule). Traditionally a wire ferrule is crimped to a stranded wire using a crimping tool (compression, ratchet, or pneumatic mechanism), thus turning the stranded wire into a solid one. Wire Ferrules are offered without insulation (Non-Insulated Wire Ferrules), with plastic insulation for single wires (Single Insulated Wire Ferrules) and with a plastic insulation to accommodate two wires (Twin Wire Ferrules). Wire Ferrules are offered in Strips or Spools to be used with automatic crimping machines or multi-function crimping tools.

Dimensions & Features:

Wire Size: 22 AWG
Color: Pink
L1: 10.4mm (0.409")
L2: 6.0mm (0.236")
D: 1.15mm (0.045")
D1: 0.85mm (0.033")
D2: 2.0mm (0.079")
UL Approved: Yes
CE Certfied: Yes
RoHS Compliant: Yes
Max Electrical Rating: 105oC (221oF) - 600 Volts
Max Electrical Current: 9A

Technical Drawing:


Cross References

ABB: XUS001820
American Electrical: 1163034
Crimp Supply: 13A11003
Greenlee: 168/6
Panduit: FSF74-6-D
Uline: UL File #326725
ZF: V3AE1664
